B2 Audio RIOT Series V2 10" 750 Watt RMS Dual 4-Ohm 3" Voice Coil Subwoofer

• Unleash the power of 750 Watts RMS for dynamic and impactful bass performance.
• Dual 4-ohm impedance and 3" voice coil offer flexibility and superior audio quality.
• Engineered for precision with 18mm XMAX and a massive 240 oz magnet.
• Versatile enclosure options support sealed and ported designs for customized sound.
• Built for durability and reliability with premium materials and rugged construction.

10" 750 Watts RMS Dual 4-Ohm 3" Voice Coil Riot Series Version 2 Subwoofer

This Listing Includes:

• (1) B2 Audio 10" 750 Watts RMS Dual 4-Ohm 3" Voice Coil Riot Series Version 2 Subwoofer

The B2 Audio Riot Series Version 2 10" Subwoofer redefines performance and power with a compact design and robust features. With 750 Watts RMS and a peak power handling of 1500 Watts, this subwoofer is engineered for dynamic, deep bass. It boasts a dual 4-ohm impedance configuration and a powerful 3-inch voice coil, providing versatility and optimized sound quality. Built with a 240 oz magnet and advanced materials, the Riot V2 subwoofer delivers precise low-frequency performance while ensuring durability. Whether you're upgrading your car audio system or building a custom setup, this subwoofer is the ultimate choice for high-performance sound enthusiasts.

Specifications

• Sensitivity: 83.1 dB


• Nominal Impedance: Dual 4-Ohm


• DC Resistance: 3.2 Ohm


• Voice Coil Dim: 3"


• Power Handling: 750 Watts RMS


• Peak Dynamic Power: 1500 Watts


• XMAX One Way: 0.708661in  / 18mm


• VAS: 12.5 L


• FS: 36.9 Hz


• QES: 0.72


• QMS: 6.06


• QTS: 0.64


• CMS: 70 um/N


• MMS: 241.2g


• BL^2/RE: 82.6


• Magnet: 240 Oz


• Displacement: 3.7L / .13cu.ft

Dimensions

• Overall Diameter: 10.82" / 275 mm


• Overall Depth: 8.30"


• Front Mount Baffle Cutout: 9.25"


• Mounting Depth: 6.53"


• Motor Diameter: 7.40"


• Weight: 24.25 LBS

Enclosure Suggestions

Sealed

• 20 L/ .371 cu. ft Qtc 1.1

Ported Compact

• 35L / 1.236 cu.ft / P:4" L: 15.74" / 40 cm / FB: 38 Hz

Ported

• 50 L / 1.76 cu/ft / P:4" L: 10.64" / 27 cm / FB: 32 Hz

BP 4th

• 3:1 Ratio
