B2 Audio RAGE Series 8" 4-Ohm 250 Watt RMS Mid-Range Speakers UV-Coated Cone, Sold in Pairs RAGE8P

• 300W RMS Mid-Range Power: delivers strong, clean vocals and aggressive mid-bass for high-output systems.
• 4-Ohm Impedance: ensures wide amplifier compatibility and easy system integration.
• 2.4" CCAR Voice Coil: provides excellent thermal stability and reliable long-term performance.
• Neo/Ferrite Hybrid Motor: boosts efficiency, output, and overall dynamic response.
• UV-Treated Paper Cone: with dual cloth surround delivers crisp, accurate sound across the 87 Hz – 10 kHz range.
• High 99.7 dB Sensitivity: produces loud, detailed output even at lower power levels.
• Ideal for Doors, Kick Panels, and Pro-Audio Builds: where clean and powerful mids are essential.

B2 Audio RAGE8P Pair of Rage 8" 4-Ohm 300 Watt RMS Mid-Range Speakers

This Listing Includes:

• (2) B2 Audio Rage 8" Speakers


• (2) Set of Hardware

Experience high-output clarity and aggressive mid-range performance with the B2 Audio RAGE 8" 4-Ohm mid-range speakers. Engineered for power, precision, and true musical impact, the RAGE8P delivers 300W RMS of clean, dynamic sound with exceptional efficiency and detail.

With a lightweight UV-treated paper cone, dual cloth surrounds, and a powerful Neo/Ferrite hybrid motor, these speakers produce crisp vocals, sharp instrumentation, and punchy upper bass. Whether used in a car audio system, doors, kick panels, or pro-audio style builds, the RAGE8P brings unmatched output and accuracy.

Perfect for daily builds, stage-3 door upgrades, and high-performance soundstage setups.

Features

• 300W RMS / 600W Max power handling for strong, controlled mid-range output


• 4-ohm impedance for wide amplifier compatibility


• 2.4" CCAR voice coil offers high thermal stability and reliability


• Neo/Ferrite hybrid motor provides exceptional efficiency and motor strength


• UV-treated paper cone delivers clean, natural mid-range reproduction


• Dual U-shaped cloth surround supports fast, accurate movement


• High 99.7 dB sensitivity for loud output even at lower power


• Wide frequency response from 87 Hz to 10 kHz


• Ideal for door panels, pro-audio builds, and high-output systems

Specifications:

• Nominal Chassis Diameter: 8.31 / 211 in/mm


• RMS Power Handling: 300W


• Max Power Handling: 600W


• Nominal Impedance: 4 Ohm


• Voice Coil Diameter: 2.4"


• Winding Material: CCAR


• Frequency Response: 87 Hz ~ 10 kHz


• Sensitivity: 99.7 dB


• Resonance (Natural) Frequency: 87 Hz


• Magnet Weight: 41.5 oz


• Magnet Type: Neo / Ferrite


• Cone Material: UV Treated Paper


• Surround Type: Dual U Shaped Cloth

Thiele & Small:

• Free Air Resonance (Fs): 87 Hz


• Resistance (Re): 3.3 ohm


• Mechanical Factor (Qms): 11.025


• Electrical Factor (Qes): 0.256


• Total Factor (Qts): 0.251


• Equivalent Volume (Vas): 14.69 L


• Compliance (Cms): 110 um/N


• BL Factor (BL): 10.79 T/M


• Moving Mass (Mms): 16.4 g


• Excursion Max (Xmax) (One Way): 0.20" / 5 mm


• SD: 226 cm squared


• Efficiency: 3.742 percent


• Le (1 kHz): 0.303 mH


• EBP: 339.8

Dimensions:

• Overall Diameter: 8.3" /211mm


• Bolt Circle Diameter: 7.48" / 190mm


• Baffle Cutout Diameter: 7.13" / 181mm


• Total Depth: 3.35" / 85mm


• Mounting Depth: 3.05" / 77.5mm


• Net Weight(1 PC): 3.41 kgs


• Shipping Weight (1 PC): 4.32 kgs


• Shipping Box (1 PC): 257 x 241 x 110 mm
