B2 Audio 6 input 10 output Channel DSP Bluetooth with IOS/Android App 96 KHz - 32 Bit

B2 Audio 6 input 10 output Channel DSP Bluetooth with IOS/Android App 96 KHz - 32 Bit

SKU:B2-DSP-SIXTEN

CASE QUANTITY: 20

PACKAGE WEIGHT: 1.06 LB

Regular price $161.95
Regular price $179.95 Sale price $161.95
Sale Sold out
  • Advanced Digital Signal Processing – 6-input, 10-output DSP with 96 kHz, 32-bit resolution for crystal-clear audio and precise tuning.
  • Wireless Control via Bluetooth – Adjust settings effortlessly using the iOS & Android app, offering real-time customization from your smartphone.
  • High-Voltage Output for Optimal Performance – Each of the 10 output channels delivers a 4-volt signal, ensuring maximum clarity and power for your audio system.
  • Compact and Durable Design – Engineered for seamless integration into any setup with a space-saving 4.5” x 5.75” x 1.5” form factor.
  • Professional-Grade Sound Quality – Designed for audiophiles and car audio enthusiasts seeking precise frequency control, low distortion, and superior sound staging.


B2 Audio 4v 10 Channel DSP with Bluetooth IOS/Android App 96 KHz - 32 Bit


This listing includes



  • (1) B2 Audio SIXTEN, 6 Input - 10 Output 4v DSP


The B2 Audio SixTen DSP is a cutting-edge 6-input, 10-output digital signal processor designed for unmatched audio customization. With Bluetooth connectivity and an intuitive iOS/Android app, it delivers precise tuning through its 96 kHz, 32-bit resolution. Each of the 10 output channels provides a strong 4-volt signal, ensuring optimal performance for high-quality car audio setups.


Technical Specifications



  • Inputs: 6 (3 Left/3 Right)

  • Connectors: RCA

  • Input Level Max: 4.00 Vrms (+ 14dBu)

  • Outputs: 10

  • Output Max Level: 3.50 Vrms (+ 13dBu)

  • Frequency Response: 10Hz to 24KHz (-1dB)

  • THD+N: <0.01%

  • Signal Latency: <0.6 ms

  • Bit Rate: 32-Bit

  • Sampling Frequency: 96khz

  • Voltage DC: 9.5 - 15v DC

  • Maximum consumption: 350mA


Processing Technical Documents


Channel Routing:



  • Routing Option: A/B/C/D/A+B/A+C/B+C


Gain:



  • General Gain: -53 to 0dB

  • Channel Gain: -33 to +9dB


Frequency Cut:



  • Cut-Off Frequency: 20Hz - 20KHz

  • Type of Cuts: Linkwitz-Riley / Butterworth / Bessel

  • Attenuations: 6/12/18/24/36/48 dB/8 degrees


Input Equalizer (EQ in):



  • Equalization Band: 31 Bands

  • Gain: -12 to +12dB


Channel Equalizer (EQ Channel):



  • Equalization bands: 8 parameter per channel

  • Gain: -12 to +12 dB

  • Q Factor: 0.6 - 9.9


Time Alignment (delay):



  • Time: 0 to 18.95 ms

  • Distance: 0 to 6500mm


Limiter:



  • Threshold: -53 to +6dB

  • Attack: 1 to 200ms

  • Release: 1 to 988ms


Polarity Inversion (Polarity):



  • Inversion: 0 or 180 Degrees


Memory (Preset):



  • Memories: 3-100% Configurable


Product Dimensions:



  • Length: 4.5"

  • Width:  5.75"

  • Height: 1.5"

  • Weight: 13.6 oz


App Instructions


If you are downloading the Android App, your phone may require additional permissions to install this file. Search "How to install apk files on my ____ android phone" online, fill in the blank with your phones model.



  • Download the app from the QR Codes in the owners manual or from the download links on the manufacturer website.

  • The default password for the DSP is 000000 - to set a new password, just enter any password other than 000000. If you forget your own password, press and hold the reset button for 15 seconds to reset the device to factory settings. (This will also reset all of your settings saved in the app.)
