B2 Audio MANI Pair of 1" Voice Coil 30W Silk Dome Neodymium Tweeters MANI-10TW

• High-Quality Sound: Enjoy clear and crisp highs with these silk dome tweeters, perfect for enhancing your car audio system.
• Powerful Performance: Each tweeter handles up to 30W RMS power, providing ample volume and detail to your music.
• Easy Installation: Designed for straightforward mounting with each tweeter pre wired, and included tweeter housing for precise fitment in your vehicle.
• Versatile Compatibility: With a nominal impedance of 4 Ohm, these tweeters are compatible with a wide range of car audio setups.
• Clear Highs: Experience clear and detailed highs with the B2 Audio MANI 1" Silk Dome Tweeter's SPL of 84 dB, perfect for enhancing your car audio system.

B2 Audio MANI Pair of 1" Voice Coil 30W Silk Dome Neodymium Tweeters MANI-10TW

This Listing Includes:

• (2) 1" VC 30W Silk Dome Tweeters


• (2) Angled Tweeter Housings

Item Description

Enhance your car audio experience with the B2 Audio MANI 1" Silk Dome Tweeters from the REFERENCE series. Designed to deliver clear and detailed highs, these tweeters are the perfect addition to your car audio system. With a power handling of 30W RMS per tweeter, they provide ample volume and clarity to your music. Installation is a breeze with included mounting dimensions, ensuring a precise fit in your vehicle. With a nominal impedance of 4 Ohm and Frequency Response range of 50 Hz ~ 25 KHz, these tweeters are compatible with a wide range of car audio setups. Experience superior sound quality on the road with the B2 Audio MANI tweeters.

These tweeters do not include inline capacitors (bass blockers). To protect them from damaging low frequencies, we recommend wiring a non-polarized capacitor in series with each tweeter:

• 2.2 F @ 4 Ohm > ~18,000 Hz cutoff - Provides maximum protection by blocking nearly all midrange and bass. Tweeter will only play the very top end. Best choice for basic installs or when safety is the priority.


• 3.3 F @ 4 Ohm > ~12,000 Hz cutoff - Balanced option. Allows upper treble and some presence range through while still blocking harmful lower content. Great for most 2-way or 3-way systems.


• 4.7 F @ 4 Ohm > ~8,500 Hz cutoff - Extended high-pass. Lets more upper mids and highs pass through for a smoother blend with midrange speakers. Requires careful tuning to avoid overpowering the tweeter.

Features

• 1" silk dome tweeters for smooth and natural high-frequency response


• 30W RMS power handling per tweeter for detailed sound at any volume


• Neodymium motor structure for compact yet powerful performance


• Frequency response from 1250 Hz to 25 KHz for crisp, extended highs


• 4-ohm impedance ensures easy integration with most systems


• 84 dB sensitivity delivers clean output with minimal distortion


• Included angled housings allow flexible installation options


• Precision-engineered mounting dimensions for a clean OEM fit


• Ideal for OEM upgrades or reference-grade sound systems


• Sold as a matched pair with all necessary hardware included

Tweeter Specifications:

• RMS Power Handling: 30W


• Nominal Impedance: 4 Ohm


• Voice Coil Diameter: 1"


• Frequency Response: 1250 Hz ~ 25 KHz

Thiele & Small Parameters

• Free Air Resonance (Fs): 1250 Hz


• Resistance (Re): 3.9 ohm


• Mechanical Factor (Qms): 0.76


• Electrical Factor (Qes): 2.43


• Total Factor (Qts): 0.58


• Equivalent Volume (Vas): 0.001 L


• Compliance (Cms): 5.7 um/N


• BL Factor (BL): 6 TM


• Moving Mass (Mms): 2.8 g


• Sound Pressure Level (SPL): 84 dB

Measurements:

• Overall Diameter: 2.19" / 55.8mm


• Mounting Diameter: 1.90" / 48.4mm


• Front Mount Baffle Cutout: 1.6" / 40.6mm


• Overall Depth: 1.03" / 26.3mm


• Mounting Depth: 0.61 / 15.6mm


• Sold as: (Pair)
